( EQUIPMENT OF NON-WESTERN CONSTRUCTION )

slitting speed: 0-100 m/min

electrics: 380v/50Hz/3PH

uncoiler motor: AC 7.5kw

pinch motor: AC 90kw

slitter motor: AC 55kw

recoiler motor: AC 400kw

machine line required area: Lenghth 36m x width 8m

line direction: from left to right (facing to the operation console)

material: hot rolled coils, low carbon steel coils

tensile strength: ≤ 510Mpa

coil thickness: 1.0-8.6mm

coil width: 600-2130mm

coil ID: 610mm/762mm

coil OD: max. 2150mm

coil weight: max. 45 ton

output:

coil ID: 762mm

coil OD: max. 2150mm

width accuracy: ≤0.05mm

max. cutting cap.: 11 strips (cold rolled coil thickness 2.0mm)

slitter shaft size: OD 350x length 2400mm

slitter drive motor: AC 350kw

slitter blades material: SLD-11, HRC 60-61°

slitter blades size: OD 550xID 350mm

spacer size: OD 400xID 350mm

rubber ring size: OD 550x ID 400mm
