*** Hot Rolling Mill (Used) #4868

IN STOCK

To be revamped

– For dia. 8mm to 16mm round bars > The capacity of the Mill can be increased up to a diameter of 32mm

– Bar length: 12m

Starting Material:

– Billets 120×120/130×130/140×140mm

– Length: 4m

– Max. weight: 615kg (140×140mm billets)

– Common steel for reinforced concrete

Installed Power:

– 6000kW

Equipment List:

– Oven car

– 35t heating oven

– Bring-out unit

– Feeler

– Dia. 500mm rougher

– Rougher roll table

– 40HP flying shear

– Shear

– Dia. 350mm drive unit

– 2 x dia. 360mm intermediate stands

– 2 x dia. 330mm intermediate stands

– Dia. 250mm drive unit

– 20HP flying shear

– 4 x dia. 280mm finishing stands

– 2 x dia. 270mm finishing monoblock

– Termex

– Dia. 220mm drive unit

– Dia. 220mm tail brake / drive unit

– Double channel

– 30x7m cooling bed

– Cooling bed exit roll table with transfer unit

– Cold shear

– Shear exit roll table

– Transfer unit

– Binding machine entry roll table

– Binding machine

– Binding machine exit roll table

– Bundle accumulation supports

Full details on request

-
